SPECIFICATIONS: CERAMIC-BRIQUETTE CHAR-BROILERS
32.1”
[814mm]
4.0”
[102mm]
4.0”
[102mm]
2.4”
[62mm]
TROUGH
DEPTH
1.4” [35mm] HANDLE DEPTH MAX
15.9”
[404mm]
13.0”
[330mm]
21.2”
[538mm]
GRATE DEPTH
5.5°
HIGH GRATE
POSITION
1.4°
LOW GRATE POSITION
26.0”
[660mm]
5.3”
[136mm]
WIDTH
4.0”
[102mm]
1.7”
[43mm]
1.7”
[43mm]
7.6”
[192mm]
STRAIGHT (STD) OR FLUSH-REAR
GAS INLET w/REGULATOR
For use with Natural or Propane gas only.
Gas input ratings shown for installations up to 2000 ft., (610m),
above sea level. Please specify altitudes over 2000 ft. and gas
type when ordering.
Garland/U.S. Range products are not approved or authorized
for home or residential use, but are intended for commercial
applications only. Garland/U.S. Range will not provide service,
warranty, maintenance or support of any kind other than in
commercial applications.
3.3” (84mm) DIVIDER ON
UTBG48-AB48 and UTBG60-AB60
adjustable broilers.
* Please add 7” (178mm) in overall depth with
attachment condiment rail option
.
Part # 4531352 Rev 2 (09/09/13)
Model #
Width
In (mm)
Height
(w/std legs)
Depth
In (mm)
Total
Input (BTU)
Shipping Information
Lbs/Kg
Cu Ft
UTBG24-AB24
23-5/8 (600)
13 (330)
32 (814)
60,000
283/129
19
UTBG36-AB36
35-7/16 (900)
90,000
391/178
26
UTBG48-AB48
47-1/4 (1200)
120,000
514/283
34
UTBG60-AB60
59-1/16 (1500)
150,000
635/288
41
SUPPLY OPERATING PRESSURE
MANIFOLD OPERATING PRESSURE
INSTALLATION CLEARANCES
NATURAL GAS
PROPANE
NATURAL GAS
PROPANE
CLEARANCE: 0”
FOR INSTALLATION IN
NON-COMBUSTIBLE
SURROUNDINGS ONLY
"WC
MBar
"WC
Mbar
"WC
MBar
"WC
Mbar
7
17.5
11
27.5
4.5
11
10
24.5
