Operating instructions for hand-held pendant stations HBE and HBL
EUCHNER GmbH + Co. KG Kohlhammerstraße 16 D-70771 Leinfelden-Echterdingen Tel. +49/711/75 97-0 Fax +49/711/75 33 16 www.euchner.de [email protected]
Subject to technical modifications; no r
esponsibility is accepted for the accuracy of this information.
©
EUCHNER GmbH + Co. KG
0
91055-02-02/06
Technical data, general
Parameters Value
Housing material Polyamide
Colour Blue-grey RAL 7031
Weight 1,7 ... 3.2 kg
Operating temperature 0 °C ... +55 °C
Storage temperature -20 °C ... +55 °C
Humidity, max. 80 %
(condensation not permissible)
Degree of protection
In accordance with EN60529 / IEC529
IP 65
In accordance with NEMA 250-12
Resistance to
vibration
Vibrations (3 axes)
DIN/IEC 68-2-6
Shock (3 axes) DIN/IEC 68-2-27
EMC protection requirements EN 61000-6-2
in accordance with CE EN 61000-6-4
Technical data of
components
EMERGENCY STOP Value
Norm EN 418
Switching elements Max. 2 NC contacts
Utilization category DC-13
according to IEC 60947-5-1 U
e
=24 V / I
e
= 2.75 A
Enabling switches ZSG Value
Switching element Max. 2 NO contacts
Utilization category AC-15
according to IEC 60947-5-1 U
e
=24 V / I
e
= 3.3 A
DC-13
U e =24 V / I e = 3 A
Other components
See EUCHNER catalogue for hand-held pendant stations or
www.euchner.de
Technical data, handwheel
See relevant operating instructions for HKD
handwheeel.
Accessories
See EUCHNER catalogue for hand-held pendant
stations or www.euchner.de
