Operating Instructions Safety Switch CET.-AR-...-CH-...
46
Designation
Use
Version
Order No./item
Mechanical key release
for safety switch CET
identical locking, incl. 2 keys
098850
Mechanical key release
Replacement key
for mechanical key release, identical
locking
2 keys, identical locking
099434
Replacement key
Emergency unlocking
for safety switch CET
latching in both positions
103714
Emergency unlocking CET
Cover
for safety switch CET
and actuators CET
door hinge right
098808
CET cover right
door hinge left
098807
CET cover left
Mounting plate EMP-L-CET
for safety switch CET
106695
EMP-L-CET
Mounting plate EMP-B-CET
for actuator CET
106694
EMP-B-CET
Actuator
for safety switch CET
incl. safety screws
096327
CET-A-BWK-50X
Safety screws (spare)
for actuator CET
4 x M5 x 16
packaging unit: 100 ea.
073456
M5 x 16
Designation
Cable length [m]
Order no./item
Female plug RC18
with cable PUR
for CET-AR
18-pin + PE
1.5
092761
RC18EF1,5M-C1825
3
092816
RC18EF3M-C1825
6
077014
RC18EF6M-C1825
8
077015
RC18EF8M-C1825
10
092898
RC18EF10M-C1825
15
077016
RC18EF15M-C1825
20
092726
RC18EF20M-C1825
25
092727
RC18EF25M-C1825
30
095993
RC18EF30M-C1825
Plug connector RC18
with cable halogen-free
for CET-AR
18-pin + PE
1.5
092883
RC18EF1,5MF-C1825
3
092884
RC18EF3MF-C1825
6
092885
RC18EF6MF-C1825
8
092886
RC18EF8MF-C1825
10
092887
RC18EF10MF-C1825
15
092888
RC18EF15MF-C1825
20
092889
RC18EF20MF-C1825
25
092890
RC18EF25MF-C1825
Connection cables RC18
Accessories
Tip!
The connection cables given above meet the requirements for connection mate-
rial according to UL specifications. You will find further connection material, in
particular for series connection, in the current Non-Contact Safety System CES
catalog at www.euchner.de.
