Block diagram ces-az-abs-01b – EUCHNER CES-AZ-ABS-01B (Unicode) User Manual
Page 7
Operating Instructions Safety System CES-AZ-ABS-01B
7
24VDC
24 V
0V
CES-AZ-ABS-01B
100064
TST
EUCHNER
OUT ERR GND
SH1
K1
+
Read-
head
H11
Trans-
ponder
K2
+
H12
13
14
23
24
Block diagram CES-AZ-ABS-01B
24 V, 0 V
Power supply
H11/H12
Connection for read head 1
SH1
Shield for read head 1
TST Test
input
OUT
Semiconductor monitoring output
ERR Diagnostic
output
13, 14
Relay contact A connection,
safety relay enable
23, 24
Relay contact B connection,
safety relay enable
