Operating Instructions Safety System CES-AZ-ABS-01B
10
Electrical Connection
Warning!
In case of an error, loss of the safety function through incorrect connection.
Ì
The monitoring output OUT must not be used as a safety output.
Ì
Lay the connection cables with protection to prevent the risk of short cir-
cuits.
Caution!
Risk of damage to equipment or malfunctions as a result of incorrect connection.
Ì
All the electrical connections must either be isolated from the mains supply
by a safety transformer according IEC 61558-2-6 with limited output voltage
in the event of a fault, or by other equivalent isolation measures.
Ì
For use and operation as per the requirements, a power supply with the
feature "for use in class 2 circuits" must be used. The same requirement ap-
plies to the safety outputs.
Alternative solutions must comply with the following requirements:
a) Electrically isolated power supply unit with a max. open-circuit voltage of
30 V/DC and a limited current of max. 8 A.
b) Electrically isolated power supply unit in combination with fuse as per UL248.
This fuse should be designed for max. 3.3 A and should be integrated into
the 30 V/DC voltage section.
Ì
All electrical outputs must have an adequate protective circuit for inductive
loads. The outputs must be protected with a free-wheeling diode for this pur-
pose.
Ì
Use cable material made of copper with a temperature resistance of at least
75 °C.
Ì
The tightening torque for the screws on the connection terminals must be
0.6 ... 0.8 Nm.
Ì
The connection cable for the read heads must only be extended using
EUCHNER plug connectors and adequate consideration must be given to
EMC. Intermediate terminals must not be used.
Ì
The screen on the connection cable for the read head must be connected to
the terminal SH1 on the evaluation unit. The portion of cable from which insu-
lation is stripped should be kept as short as possible (max. 3 cm).
Safety in case of faults
Ì
The operating voltage U
B
is reverse polarity protected.
Ì
The connection for the read head is not short circuit-proof.
Ì
A short circuit between 13/14 and 23/24 can be detected only by means of
external pulsing.
Ì
A short circuit in the cable can be excluded by laying the cable with protection.
