Operating Instructions Safety Switch NM..HB
EUCHNER GmbH + Co. KG Kohlhammerstraße 16 D-70771 Leinfelden-Echterdingen Tel. +49/711/75 97-0 Fax +49/711/75 33 16 www.euchner.de [email protected]
Subject to technical modifications; no r
esponsibility is accepted for the accuracy of this information. © EUCHNER GmbH + Co. KG
084462-04-11/10 (translation of the original operating instructions)
Figure 6: Changing the lever arm Figure 7: Changing the switching direction
Figure 5: Dimension drawing NM01HB, NM...C2069
*fixed positioning for safety-
related applications (M5)
1,
5
25
18
16,5
17
27
25
R6
∅4,2
M16x1,5
M16x1,5
M=0,6Nm
*
M=1 Nm
∅5
12,5
32 8
12,5
16
32
128,
5
25
46
0°
35
°
60
° 6 5
°
0°
45
° 60
° 6 5
°
35
°
A
Standard
B
C D
M=0,6Nm M=0,6Nm
41
+1 0
13-14
21-22
31-32
11-12
21-22
31-32
NM03 NM02 NM12 NM11
Dog
Simultaneously press
and rotate the washer
Rotate the
actuating
element
Left
switching
Left / right
switching
(default setting)
Right
switching
-90° 0° +90°
Figure 4: Dimension drawing NM11HB / NM02HB / NM12HB / NM03HB
Dog
*fixed positioning for safety-related applications
(M5)
41
+1 0
21-22
1,
5
25
18
16,5
17
27
25 R6
∅4,2
M=0,6Nm
*
M=1 Nm
0˚
35
˚
60
˚ 65
˚
∅5
12,5
32 8
32
97,
5
25
46
M16x1,5
A
Standard B
C
D
M=0,6Nm M=0,6Nm
0˚
35
˚
60
˚
65
˚
21-22
31-32
NM02
(C2069)
NM01
0˚
45
˚
60
˚
65
˚
35
˚
13-14
21-22
NM11
(C2069)
The lever arm can be adjusted to positions every 10°. Depending on the application, the
lever with roller can also be rotated to the outside or the inside. After setting the required
approach direction, the lever arm is fastened using the screw.
Exclusion of liability under the following
circumstances
incorrect use
non-compliance with safety regulations
installation and electrical connection not performed
by authorized personnel.
failure to perform functional checks.
EC declaration of conformity
The manufacturer named below herewith declares that
the product fulfills the provisions of the directive(s)
listed below and that the related standards have been
applied.
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16
70771 Leinfelden-Echterdingen, Germany
Directives applied:
Machinery directive 2006/42/EC
Standards applied:
EN 60947-5-1:2004 + Cor.:2005 + A1:2009
EN 1088:1995+A2:2008
Leinfelden, July 2010
Dipl.-Ing. Michael Euchner
Director
Duc Binh Nguyen
Authorized representative empowered to draw up
documentation
The signed EC declaration of conformity is included
with the product.
