E T C I n s t a l l a t i o n G u i d e

Echo™ Light Sensor

Page 5 of 12

Echo Light Sensor Installation Guide

Step 4: Orient the smooth side of the mounting plate to the junction box. Pull

the following wires from the junction box through the provided holes of
the mounting plate:

• EchoConnect bus wires or EchoConnect pigtail and ESD ground wires

depending on the installation.

• Remote Light Sensor Head wires (if remotely mounting Light Sensor

Heads).

Step 5: Secure the mounting plate to the junction box using the screws

provided (both short and long screws are included for convenience).

Step 6: Strip each wire 5/16” (8mm) and terminate the EchoConnect (white

and black wires) and ground wire (green/yellow) to the EchoConnect
terminal block located on the sensor controller. Torque each
termination to 3.1-3.5 in-lb.
a: Terminate the white incoming wire to the data + terminal.
b: Terminate the black incoming wire to the data - terminal.
c: Terminate the green/yellow (ground) wire to the labeled ground

terminal.

Step 7: To terminate remote Light Sensor Heads,

See “Terminating Remote

Light Sensor Head Control Wiring” on page 8.
