The following section of this manual contains details which address the installation of insulated metal
wall panels and their associated flashings. The details are generic, showing typical wall framing and
flashing conditions. Because of the many variations of applications and construction conditions, these
generic details may vary from the project’s actual conditions. Always reference the project’s
installation drawings for the specified requirements. If there are differences between the installation
drawings and these installation guide details, the installation drawings will govern.
1. Panel Side-Lap (Joint)
2. Base
3. Outside Corner
4. Inside Corner
5. Door Header (Supported)
6. Door Header
7. Door Jamb
8. Window Header
9. Window Jamb
10. Window Sill
11. Stack Joint
12. Side Joint
