2.02

Panel System should be the Englert Series 2400, 1-1/2” seam x 16” or 20” wide panel or 2” seam x 18” wide panel
Structural Standing Seam System, (with pencil ribs and 2 mechanically seamed styles available). mechanical seaming
available in 90 degrees and 180 degrees. The panels shall have baked on finsh as specified in Seciton 2.05 hereunder,
in Manufacturer’s standard colors. Manufacturer shall offer at least a minimum of 23 standard colors to choose from.

Substrate:

24 Gauge baked on finish over Galvalume ASTM A-792-83, AZ50, 50 KSI yield point, 52 KSI tensile strength

* 22 Gauge baked on finish over Galvalume per ASTM A-792-83, AZ50, 50 KSI yield point, 52 KSI tensile

strength.

* .032” or .040” Aluminum Alloy 3105-H14 approved equal.

NOTE TO SPECIFIER: *22 gauge steel, and .032” and .040” aluminum are available subject to minimum
order requirements. Call Englert for details.

Performance:

1. Panel shall meet the requirements of Underwriter’s Laboratories, Inc. for Class 90 wind uplift resistance.
2. ASTM E-283-84 Air Infiltration: Maximum of 0;003 CFM./Ft2 at 10 psf pressure differential on 180 degrees

seamed profile and 0.006 CFM./Ft2 at 20 pst pressure differential.

3. ASTM E-331-84 Water Penetration: No evidence of uncontrolled leakage on 180 degrees seamed panel at 20

psf pressure differential.

4. Panel shall display a flame spread classification of a (Class 1) when tested in accordance with

ASTM E-84-87.

5. Panel system shall be tested in accordance with ASTM-E-1680-95, standard test method for rate of air leakage

thorugh exterior metal roof panel systems.

6. Panel system shall be tested in accordance with ASTM-E-1646-95, standard test method for water penetration

of metal roof panel systems by uniform static air pressure difference.

7. Panel system shall be tested in accordance with ASTM-E-1592 wind uplift criteria.

NOTE TO SPECIFIER: Series 2400 Panels 2” x 18” wide in 24 gauge Galvalume meet the UL-580, Class-90

when installed over purlins at 4’0” o.c. with special clips.

IF METAL SOFFIT IS REQUIRED, SPECIFY AS FOLLOWS:

2.03 SOFFIT PANEL SYSTEMS

Soffit Panels: Series 2400 Panel System is not recommended for use as a soffit system.

2.04 FABRICATION

Panel Construction: Panels shall be uniformly dimensioned, rollformed to exact lengths to avoid trimming. The panel
system shall be anchored as recommended by the Manufacturer. All fasteners shall be concealed. Panels shall be
continuous from ridge to eaves with no end laps. There shall be no face penetration of panels, except as approved by
the architect for securing panels to facilitate directional expansion/contraction.

Flashing and Trim: All exposed standard or special flashing/trim and such other brakeformed in the same gauge, color,
and finish to match roofing panels, furnished with protective strippable film to be removed upon installation.

Accessories such as clips, closures, fasteners, etc., shall be as recommended by the Manufacturer.
