Series 1000 Panel System may be specified for application over solid deck, 5/8” plywood with 2 layers of 15# felt or 1 layer of 30#
felt or 22 gauge metal deck with 2 layers of 15# felt or 1 layer of 30# felt, minimum pitch 3”/12” (specify as required).
2.02
A.
Panel System should be Englert Series 1000, 1-1/2” x 16” Architectural Snap-Lock Standing Seam System (with
pencil ribs, optional). The panels shall have baked on finish as specified in Section 2.05 hereunder, in
manufacturer’s standard colors. Manufacturer shall offer at least a minimum of 23 standard colors to choose from.
B.
Substrate:
?
24 Gauge baked on finish over Galvalume ASTM A-792-83, AZ50, 50 KSI yield point, 52 KSI tensile
strength
?
26 Gauge baked on finish over Galvalume ASTM A-792-83, AZ50, 50 KSI yield point, 52 KSI tensile
strength
?
* .032” or .040” Aluminum Alloy 3105-H14 approved equal.
NOTE TO SPECIFIER: .032” and .040” aluminum are available subject to minimum order requirements. Call
Englert for details.
C.
Performance:
1. *Panel Shall meet the requirements of Underwriter’s Laboratories, Inc. for Class 90 wind uplift resistance.
2. Air Infiltration/water penetration: No evidence of uncontrolled leakage on Snap-Lock Seam at 100 mph with
simulated water spray of 8.8” of rainfall per hour.
3. Panel shall display a flame spread classification of a (Class 1) when tested in accordance with ASTM E-84-87.
*NOTE TO SPECIFIER: Series 1000 Panels 16” and 20” wide in 24 gauge Galvalume meet the Underwriter’s
laboratories, Inc. 580 classification for 90 lb./square foot uplift test when installed over solid 5/8” plywood deck
with 2 layers of 15 lb. felt with clips at 18” oc.
IF METAL SOFFIT IS REQUIRED, SPECIFY AS FOLLOWS:
2.03 SOFFIT PANEL SYSTEMS
A.
Soffit Panels: Series 1000 16” wide flat panels, all fasteners shall be concealed, and panels shall give a flush
appearance, with pencil ribs, optional. The soffit panels shall have the same finish as the roofing system.
B.
Substrate:
?
24 Gauge baked on finish over Galvalume ASTM A-792-83, AZ50, 50 KSI yield point, 52 KSI tensile strength
?
26 Gauge baked on finish over Galvalume ASTM A-792-83, AZ50, 50 KSI yield point, 52 KSI tensile strength
?
* .032” or .040” Aluminum Alloy 3105-H14 approved equal.
NOTE TO SPECIFIER: .032” and .040” aluminum are available subject to minimum order requirements. Call
Englert for details.
2.04 FABRICATION
A.
Panel Construction: Panels shall be uniformly dimensioned, rollformed to exact lengths to avoid trimming. The panel
system shall be anchored as recommended by the Manufacturer. All fasteners shall be concealed. Panels shall be
continuous from ridge to eaves with no end laps. There shall be no face penetration of panels, except as approved by
the architect for securing panels to facilitate directional expansion/contraction.
B.
Flashing and Trim: All exposed standard or special flashing/trim and such other brakeformed in the same gauge,
color, and finish to match roofing panels, furnished with protective strippable film to be removed upon installation.
C.
Accessories such as clips, closures, fasteners, etc., shall be as recommended by the Manufacturer.
