V. MAINTENANCE
1. Ball Valve Seal Kits
The Single Body Valve body assemblies require very little maintenance. If it does become necessary
to service a ball valve body, seal kits are available to provide all O-rings and seats required in the
valve assembly.
Additional kits are available that also include the valve ball in the case of severe waterway
debris damage.
Table 3
Swing out instructions for accessing internal waterway.
1. Remove three of the end-cap bolts on each side of the valve away from the desired
swing-out direction.
2. Loosen the remaining two bolts (one on each side of the valve).
3. Rotate the valve out from the end caps pivoting on the remaining two end cap bolts.
4. After servicing the valve, ensure the two seats are secured in the valve body. Ensure the valve ball
is in the closed position, and rotate the valve back in line with the end caps.
5. Replace all the end cap bolts and tighten in an X pattern to the torque specified in Table 2 (page 8).
Do not lubricate the valve ball or seats.
Part Number Description Valve Size
65499000 Seal Kit SB10
65982000 Seal Kit with Stainless Steel Ball SB10
65983000 Seal Kit SB15
65984000 Seal Kit with Stainless Steel Ball SB15
