5
OVERVIEW
Spit-Fire® Monitor Featuers:
 Construction: All brass with vaned 4” waterway
 Mounting Flange: 4” 150# flat-face ANSI flange raised face flange available as option
 Discharge: 3½” NHT male outlet
 Stream Shaper: #284-B brass shaper included
 Flow: 2000 GPM max flow @ 200 PSI max working pressure
7600 LPM @ 14 BAR
 Motors: 120 VAC NEMA 4 rated synchronous motors (non-arcing)
o Constant torque and current output in start, running, and stall
o ATEX Certified to II 3 G c (Ex nA II T4)
o Will not cause damage or increase in current when motor is stalled
o Instantaneous start, stop, and reverse
o Residual (Power Off) torque is always present
o Long life and exceptional reliability
o 120 VAC, 50/60 Hz., 1 Phase, 0.80 Amp current per motor
 Junction Box: NEMA #4X (IP-66) water tight, corrosion resistant ATEX certified (Ex eII T6),
enclosure with terminals for hazardous locations. Stainless Steel motor
cable junction box with bracket to attach to monitor, flange base included.
 Range of Motion: Monitor stops are factory set at 346° horizontal (+173° to -173° from front
center), and 135° vertical (+90° to -45°)
 Rate of Horizontal Motion: 0.139 Sec/°
 Manual Override: Hand wheels provided for vertical and horizontal movements. Hand wheel
will not rotate when monitor is operated electrically.
 CE ATEX Certified (Group II, Category 3) II 3 G c T3
Warning:
DO NOT TAKE COVER OFF OR DISASSEMBLE MONITOR MOTORS. If
cover is/has been removed, the warranty is void and the service life of the motor is
significantly reduced.
