Dreams Piccadilly TV Bed - Manual (Page 4)

Stage
3
Bed
Bed Assembly continued
9
9
9
A x2 G x2
Stage
4
A x4 B x4 C x4
Push bolt ( A) through spring washer (B) and flat washer (C),
Hold tray firmly against side panel ( 4) as shown and screw-in x4 bolts.
When all screwed in place, tighten bolts 100%.
Adjust the feet ( G) so bottom of tray is level.
Fit the adjustable feet ( G) to the underside
of the tray support legs ( 9) screw into place.
Fit the support legs ( 9) to the underside of
the tray base panel using the bolts ( A) to
secure. Fully tighten using the Allen Key ( E).
Assembly
Page 4 of 9
4
