Dreams Piccadilly TV Bed - Manual (Page 2)

Page 2 of 9
Qty Code Description
This assembly requires two
people.
A x22 Bolt (M8x30mm)
Fittings Checklist
B x20 Spring Washer
C x20 Washer (17x8mm)
D
E
x13 Screw (5x50mm)
F
x1 Allen Key (8mm)
Additional Tools Required
x13 Barrel Nut
H
Qty Code Description
G x2 Adjustable Foot
General Hints & Tips
Intersecting
Hole
Crosshead Screwdriver
We recommend the bed is
assembled in the room it will
be located in.
These parts are supplied with the optional
sprung slat frame.
O Bolt (M6 x15mm)
x8
Bolt (M6x40mm) x6
x6 Sleeve Nut (M6x6mm)
x6 Washer (16x6mm)
K x1 Allen Key (6mm)
I
J
Please retain your Assembly Instruction and
tools provided, for future use. Periodically
check that all bolts are still tight.
When they are supplied and are part
of the assembly of this bed, ensure
that barrel nuts are fitted the correct
way so the hole is facing towards the
intersecting hole.
x4 Screw-Washer set x1 Allen Key M N
TV INSTALLATION KIT
L x2 Cable Clip
Care & Maintenance
In the unlikely event of missing or damaged parts, please
contact the customer service team on 08442 920000. When
calling this number , please quote the part code reference
numbers shown in this leaflet, to properly identify spare or
replacement parts.
To keep your bed in pristine condition, wipe over with a clean,
slightly dampened cloth.
P
Q
Centre Support Leg
Support Leg
x1
x2
