12
Figure 10. – Typical Wiring (7505P)
Section: Wire the Burner
LIMITS
DETECTOR
A
K
D A
A
C
F
SUPPLIED BY INSTALLER
FROM FUSED DISCONNECT SWITCH
LINE VOLTAGE SERVICE 120V 60Hz
OPERATOR
A
L1 L2
TRANS
S1
MOTOR
7505P
S2
A D
GND
GND
TERMINAL
EQUIP
LMT
L1
IGN
TR
TW
VLV
CAD
CAD
MTR
L2
B
B
Legend
L1 Line 1 Power (Hot)
L2 Line 2 Power (Neutral)
LMT Limit control Terminal
MTR Motor Control Terminal
S1 Oil Valve
S2 Oil Valve (on Cleancut Pump)
TRANS Ignition Transformer
VLV Valve Control Terminal
Factory Wiring
Wiring Supplied by Installer
