LED indicators
The LED indicators on the front of the DMX DECELERATOR have the following
functions:
LED label Function
SIGNAL On when DMX input is present. It is off when DMX is not present and
the HOLD LAST LOOK feature is disabled (default). It flashes when no
DMX is present and the HOLD LAST LOOK feature is active.
MIMIC Tracks the current level of dimmer 1 for troubleshooting purposes
PWR On when power is on
Jumper settings
Internal jumpers can be removed to change the behavior of the DMX DECELERATOR’s
output. To access the jumpers, remove the 4 screws which hold the front panel in
place. With the screws removed, the front panel can be removed and the top cover
panel can be slid out giving access to the jumpers on the circuit board. The jumpers
have functions as shown in the table below.
Jumper Installed function (default) Removed function
JP1 No output on loss of DMX input Hold last look on loss of DMX input
JP2 Disable driver on loss of DMX Leave driver enabled on loss of DMX
JP3 Use front panel switch for timing Set output for Strand timing
JP4 Unused Unused
JP5 Unused Unused
Warranty
Products manufactured by Doug Fleenor Design carry a five year parts and labor
warranty against manufacturing defects. It is the customer's responsibility to return the
product to Doug Fleenor Design (at the customer's expense) for service. Doug Fleenor
Design will repair the unit and return it to the customer (at Doug Fleenor Design's
expense). If a trip is necessary to the customer's site to solve a problem, the expenses
of the trip must be paid by the customer.
1. Note that this warranty is against Manufacturing Defects. It does not include damage
due to misuse or abuse. Most non-warranty repairs are made for a fixed $30.00 fee.
