Section 3 - Controls and Indicators
3-21
31200751
3.4
OPERATOR SEAT
Operator Presence
The operator seat (1) is equipped with an operator presence switch. If the switch
detects a loss of pressure during operation, after a two second delay one of the
following will occur:
1. With the park brake (2) disengaged and the transmission in neutral (3):
• Horn sounds continuously.
• Upon returning to seated position, horn will cease.
2. With the park brake (2) disengaged and transmission in forward or reverse (3):
• Horn sounds continuously, transmission shifts to neutral and boom joystick
(4) is disabled.
• Upon returning to seated position, horn will cease and boom joystick is
enabled. Return transmission to neutral to allow system to reset prior to
reengaging forward or reverse travel.
OAL3850
3
2
4
1
