Now place the cover supplied on the printer. This cover replaces the
front cover previously removed and serves as a support for the feed
mechanism.
Holding the cover at a 45 degree angle place it on the printer as shown
in the diagram.
First place the recess on the left side of the cover in the mounting pin on
the printer (
➀ ). Then insert the holder on the right side ( ➁ ) into the pin
on the printer and turn the cover down.
Starting on the next page the description is again valid for all models !
↓ ↑ ↓ ↑
➁ ➀
ENGLISCH
Installing the face down option
5
