HOW TO OPERATE:
WARNING:
Be sure gun is always pointed in a safe direction. Never point the gun
at anyone. Always assume and handle the gun as if it were loaded and ready to fire.
Step 1. OPEN BOLT
Pull the bolt handle fully to the rear. Then, release your hold on the bolt handle, leaving the bolt
open. The gun cannot fire with the bolt open. (See Drawing 1A)
Step 2. PUT “ON” TRIGGER SAFETY
The bolt must FIRST be opened, then the trigger safety is pushed from the left to right so that
NO red is showing (See Drawing No. 1B). It is a good practice to get into the habit of always
keeping the trigger safety “ON” until actually ready to fire the gun.
Step 3. PUMP (ONCE)
IMPORTANT: Do not pump over one time. This gun is
designed to produce a maximum velocity using a single
pump stroke. Additional pump strokes may result in
serious damage to the gun. The bolt must be opened to
pump gun. For greater safety, we recommend that the
bolt remain open while pumping and that you close the
bolt only when the barrel can be pointed in a safe
direction.
Grasp the pump handle. Pull out and forward as far
as possible. You should hear a fresh charge of air being
drawn into the pump cylinder. Then, return the pump
lever to the original, closed position. (See drawing 2)
3
Step 1. OPEN BOLT
Step 2. PUT “ON” TRIGGER SAFETY
Step 3. PUMP ONCE
Step 4. LOAD Step 5. CLOSE BOLT
Step 6. AIM AT SAFE TARGET
Step 7. TAKE “OFF” TRIGGER SAFETY
Step 8. FIRE
BOLT HANDLE
FEED
TRACK
TRIGGER
SAFETY
NO. 1B
TRIGGER
SAFETY ON
TRIGGER
SAFETY OFF
red showing on
opposite side
PULL LEVER
OUTWARD FOR
FULL STROKE
THEN RETURN
PINCH
DOVETAIL GROOVES
NO. 1A
