13
Maintenance
A. GENERAL PROCEDURES
!CAUTION: Any customer repairs not authorized by the
manufacturer relieves the manufacturer of any responsibility for
any resulting damage of property or injury to personnel.
B. FLUID LEVELS
Due to safety and/or regulatory reasons, this machine may arrive without
hydraulic oil and fuel.
Fill the levels as per the following table:
Fluids Quantity
Hydraulic oil level (table 1, pos. 1) 100 l – 26.4 gal
Engine oil level (see enclosed engine booklet)
Fuel level (table 1, pos. 4) 28 l – 8 gal
Negative brake for bull-wheel oil level (table 1, pos. 8) 0.3 l – 0.08 gal
Negative brake for reel winder oil level (table 2, pos. 3) 0.4 l – 0.1 gal
!CAUTION: Not filling fluids to those levels specified above will
cause serious damage to system components and voids all
product warranties.
!DANGER: Purposely ingesting hydraulic liquids, fuels and cooling
liquids is potentially lethal.
C. SUGGESTED LUBRICANTS
The manufacturer tests the machine with the following oils and lubricants:
hydraulic circuit and negative brake: IP HYDRUS OIL 46 (ISO VG 46).
Alternates must be chosen from the enclosed table “SUGGESTED
LUBRICANTS”. It is possible to use different products, but they must have the
same characteristics and ISO specifications.
!CAUTION: The use of lubricants not in conformity with the
technical specifications indicated in the referenced table can
seriously damage the machine, its components and voids all
product warranties.
!DANGER: Let the engine cool prior to performing any
maintenance, or before refueling.
D. HYDRAULIC CIRCUIT MAINTENANCE
Change the hydraulic oil after 500 working hours, then every 1500 hours (or at
least annually).
To drain the hydraulic oil remove the hydraulic tank’s drain plug (table 2, pos. 6).
!DANGER: Allow the hydraulic oil to completely cool before
removing it. Always use suitable safety gear (gloves, etc.).
