Condux Mini-Blower/Pusher - Manual (Page 9)

9
6. Load cable through drive assembly. Select and install the appropriate size cable
seals for the specific project. (See figure 7)
7. Install top venturi. (See figure 8)
Blower/Pusher Operating
Instructions
A. fINAL CONNECTIONS
1. Secure the blower assembly by closing the hinged top and tightening the blower
clamp. (See figure 9)
2. Secure drive assembly by closing and locking the back clamp with locking clip.
(See figure 10)
figure 7. Select & Install Seals figure 8. Install Top Venturi
figure 9. Tighten Blower Clamp figure 10. Install Back Clamp
6.
