OPERATOR QUALIfICATIONS
a. Operator must know the required safety directives to run the machine that are
pertinent to the country where it is being used.
b. Operator in charge of the machine and installation project must be appropriately
dressed, avoiding large clothes, hanging jewelry or whatever might become
entangled in the moving parts.
c. Operator must also wear the necessary protective equipment such as gloves,
boots, helmet, etc.
d. Operator must carefully follow all advisements contained in the instruction
manual or on the machine.
e. Operator must have work area kept clean of obstacles that might inhibit a safe
working area.
mAINTENANCE QUALIfICATION
a. All of the machine maintenance must be carried out with the machine on a level
surface and not attached to any form of power source: electrical, or pneumatic.
b. Authorized and trained personnel must do all maintenance operations. Trained
personnel are defined as people who have received qualified training from the
using company or from the manufacturer.
Technical Information
A. AIR COmPRESSOR REQUIREmENTS
Pneumatic Pressure: 40 PSI (12 BAR) MAXIMUM IN MICRODUCT
100 PSI in Traditional Duct
Required Flow Capacity: 185 SCFM (11 M3/MIN) MAXIMUM
Conduit Size: 10 MM – 1.50" OD
Air hose fittings need to be compatible with Dixon “Air King” universal couplings
B. OPERATIONAL CAPACITIES
• Cable sizes: .23" TO .50" (5.8 MM TO 12.7 MM)
• Conduit sizes:10-18MM, ½", ¾",1", 1-1/4" TRUE, 1-1/4", 1-½" SDR 11 & 13.5 AND
METRIC O.D. CONDUIT; 25 MM, 32 MM, 36 MM, 37 MM,
C. PhYSICAL SPECIfICATIONS (DOES NOT INCLUDE TRIPOD OR JOB BOX)
• Height 12"
• Length 14"
• Width 8"
• Weight 17 lbs
