1.
General Information
The Condux CableGlider Cable Puller Extension Frame is designed for pulling jobs were a
longer reach and added stability are necessary. It is ideal for pulling from deep manholes
(Figure 1) or high overhead ducts (Figure 2). Extra slack can be pulled with the Extension
Frame when needed for termination.
The extension frame is designed for use with the Condux CableGlider Cable Puller and its
accessories. 2" Sch 40 GRC steel duct for the Extension Frame is not included.
CableGlider Cable Puller
Reference
IMPORTANT: The user of the Extension Frame must have a
complete understanding of the Condux CableGlider Cable Puller.
Read and understand operator’s instructions and safety manual
for the CableGlider Cable Puller before attempting to use it or the
extension fame.
2.
3
Figure 1 Figure 2
