Condux Break-Away D.Drill Swivels User Manual
Page 5
5
8
7
⁄
8
" - 1
3
⁄
8
" Dia. Swivel
1
5
⁄
8
" - 4" Dia. Swivel
Center Break
Pin
9. Internally threaded head must turn freely after assembly.
10. Apply grease to bearings through grease zerk until the grease is
visible by the internally threaded head. Use Condux 08190007
D.Drill
®
Swivel grease or a non-lithium based equivalent.
11. Wipe excess grease off outside of swivel.
12. Install the clevis pins (1
1
⁄
4
" & 1
3
⁄
8
") or clevis bolts and nuts (1
5
⁄
8
" - 4").
CENTER (BREAK) PIN
SETSCREW
ROLL PIN
BODY
EXTERNALLY THREADED HEAD
INTERNALLY THREADED HEAD
SEALS (2) (NOTE ORIENTATION)
BEARINGS (3) (NOTE ORIENTATION)
BEARING (1) (NOTE ORIENTATION)
CLEVIS BOLT AND NUT
EXTERNAL THREADED CLEVIS HEAD
INTERNAL THREADED CLEVIS HEAD
CENTER (BREAK) PIN
BODY
SEAL (1)
BEARINGS (3)
7
⁄
8
" - 1
3
⁄
8
" Dia. Swivel
Diagram 1
Diagram 2
1
5
⁄
8
" - 4" Dia. Swivel
