!WARNING: Read and understand all procedure
and safety instructions before using any Condux
product. Failure to do so may result in personal
injury or property damage. Save this user guide for
future reference.
!ADVERTENCIA: Lea y entienda todos los
procedimientos e instrucciones de seguridad
antes de usar cualquier producto Condux. De lo
contrario, puede resultar en lesiones personales o
daños materiales. Guarde esta guía del usuario
para futuras consultas.
ADVERTENCIA
Instrucciones de Operación
!WARNING: The Break-Away D. Drill ® Swivels are for
directional drilling only. Severe personal injury and
property damage could result if used with rope or
steel winch lines in cable pulling applications.
!CAUTION: Wear personal protective equipment:
hard hat, safety glasses, safety shoes, and leather
work gloves. Failure to do this could result in
personal injury.
!WARNING: Do not exceed the load capacity of the
D. Drill ® Swivel or any element in the pull string. Do
not stand directly behind the pull string. If any
component breaks, severe personal injury or
property damage could result.
Safety Section
Table 2 Continued
2 (51mm) Break Away Swivels
Swivel
Part No
Break Load Replacement Pin
LBS N Part No Color
08029200 9000 40034 08029205 RED
08029400 10000 44482 08029405 GREEN
4 (102mm) Break Away Swivels
Swivel
Part No
Break Load Replacement Pin
LBS N Part No Color
08075940 40000 177929 08075945 ORANGE
3 (76mm) Break Away Swivels
Swivel
Part No
Break Load Replacement Pin
LBS N Part No Color
08075810 12000 53379 08075815 GREEN
08075600 18500 82292 08029720 BLACK
08075800 22000 97861 08075805 YELLOW
08075820 25000 111206 08075825 BLUE
2 1/2 (64mm) Break Away Swivels
Swivel
Part No
Break Load Replacement Pin
LBS N Part No Color
08029600 12000 53379 08029605 WHITE
08029700 14000 62275 08029705 BROWN
