chiliGREEN D915GAGL User Manual
Page 65
Technical Reference
65
Table 19. Back Panel Connectors Shown in Figure 18
Item/callout
from Figure 18
Description
A
PS/2 mouse port (Green)
B
PS/2 keyboard port (Purple)
C
Parallel port (Burgundy)
D
Serial port A (Teal)
E
VGA port
F
Audio line in/Retasking Port C (Light blue)
G
Audio line out/Retasking Port D (Lime Green)
H
Mic in/Retasking Port B (Pink)
I IEEE-1394a
(optional)
J
USB ports (two)
K
LAN
L
USB ports (two)
NOTE
The D915GAG board supports a manufacturing option for no LAN subsystem. On D915GAG
boards with no LAN subsystem, the back panel LAN connector is not present.
