Back Panel Connectors
Figure 18 shows the location of the back panel connectors. The back panel connectors are
color-coded. The figure legend (Table 19) lists the colors used (when applicable).
OM16670
A
B
K F C
L
I
J G D E H
Figure 18. Back Panel Connectors
Table 19 lists the back panel connectors identified in Figure 18.
NOTE
The back panel audio line out connector is designed to power headphones or amplified speakers
only. Poor audio quality occurs if passive (non-amplified) speakers are connected to this output.
