Technical Reference
57
Table 18 lists the component-side connectors identified in Figure 20.
Table 18. Component-side Connectors Shown in Figure 20
Item/callout
from Figure 20
Description
A Rear chassis fan connector
B Front panel audio connector
C Parallel ATA IDE connector
D Chassis intrusion connector
E Serial ATA connector 0
F Serial ATA connector 1
G Serial ATA connector 2
H Serial ATA connector 3
I Front panel USB connector
J Front panel USB connector
K Main power connector
L PCI Express x16 bus add-in card connector
M PCI Conventional bus add-in card connector 1
N PCI Conventional bus add-in card connector 2
O PCI Express x1 bus add-in card connector
P Diskette drive connector
Q Front panel IEEE-1394a connector (optional)
R Front panel IEEE-1394a connector (optional)
S Front panel connector
T Front chassis fan connector
U Auxiliary front panel power LED connector
V Processor core power connector
W Processor fan connector
