chiliGREEN B5130 - Manual (Page 182)

Modules & Options
7 - 62 Bluetooth Module
7
Bluetooth Combo Driver Installation
Note this driver is required only for the combo Bluetooth and WLAN module only.
1. Before installing the driver make sure both WLAN and Bluetooth mod-
ules are powered on (use the Fn + F11 and Fn + F12 key combinations),
then insert the Device Drivers & Utilities + User’s Manual disc into the
CD/DVD drive. If a Found New Hardware window appears, click Cancel
in all windows that appear, and then proceed to install the driver as below.
2. Click Option Drivers (button).
3. Click 3./5.Install Combo BT Driver > Yes.
4. Choose the language you prefer and click OK.
5. Click Next.
6. Click the button to accept the license and click Next.
7. Click Next > (select if you want to create an icon to appear on the desktop)
Next > Install.
8. Click Finish.
9. The My Bluetooth icon will appear on the desktop and the Bluetooth
item will be installed in the Programs/All Programs menu.
10. See “Bluetooth Networking Setup” on page 7 - 66 for information on
Bluetooth networking.

High Speed Bluetooth
Data Transfer
The Combination Wire-
less LAN & V3.0 Blue-
tooth module supports
high speed (V3.0) data
transfer. However to
achieve such transfer
speeds, both devices
must support high
speed data transfer.
To obtain high speed
(V3.0) data transfer
make sure that both the
WLAN and Bluetooth
modules are powered
on.
Check your Bluetooth
compatible device’s doc-
umentation to confirm it
supports high speed data
transfer.
