System Map: Front View with LCD Panel Open

Figure 2

Front View with LCD

Panel Open

(Models A & B)

1. PC Camera

2. *PC Camera LED

*When the PC camera
is in use, the LED will
be illuminated in red.

3. Built-In Microphone

4. LCD

5. Power Button

6. Keyboard

7. Touchpad & Buttons



Wireless Device

Operation Aboard Aircraft

The use of any portable electronic transmission devices aboard aircraft is usually prohibited.

Make sure the WLAN, Bluetooth & 3G module(s) are OFF if you are using the computer aboard
aircraft by putting the system in to Airplane Mode.

Note that the Touchpad and
Buttons valid operational area
is that indicated within the red
dotted lines above.

1 3

Model A

14” (35.56cm)

Model B

15.6” (39.62cm)
