System Map: Front, Left, Right, Rear & Bottom Views (Model A)
2
1
7
8
4
6
3
Left
Right
5
Front
Rear
10 14
12
15
13 9
16
15
6
Bottom
17
18
6
18
11
Figure 5 - Front, Left, Right, Rear & Bottom Views
(Model A)
1. LED Indicators
2. Multi-in-1 Card
Reader
3. DC-In Jack
4. RJ-45 LAN Jack
5. External Monitor Port
6. Vent
7. HDMI-Out Port
8. 2 USB 3.0 Ports
9. Microphone-In Jack
10. Headphone-Out Jack
11. USB 2.0 Port
12. Optical Device Drive
Bay
13. Emergency Eject Hole
14. Security Lock Slot
15. Battery
16. Component Bay Cover
17. Hard Disk Bay Cover
18. Speakers
6
6

Overheating
To prevent your computer from overheating
make sure nothing blocks any vent while the
computer is in use.
Disc Emergency Eject
If you need to manually eject a disc (e.g. due
to an unexpected power interruption) you
may push the end of a straightened paper
clip into the emergency eject hole. Do not
use a sharpened pencil or similar object that
may break and become lodged in the hole.

USB 3.0 Port
The USB 3.0
ports
are col-
ored blue. USB
3.0 will transfer
data much faster
than USB 2.0,
and is back-
wards-compati-
ble with USB 2.0.
