chiliGREEN W550SU2 - Manual (Page 16)

12
English
System Map: Front, Left, Right, Rear & Bottom Views (Model B)
2
1
7
8
4
6
3
Left
Right
5
Front
Rear
10 14
12
15
13
9
Bottom
11
Figure 6 - Front, Left, Right, Rear & Bottom Views
(Model B)
1. LED Indicators
2. Multi-in-1 Card
Reader
3. DC-In Jack
4. RJ-45 LAN Jack
5. External Monitor Port
6. Vent
7. HDMI-Out Port
8. 2 USB 3.0 Ports
9. Microphone-In Jack
10. Headphone-Out Jack
11. 2 USB 2.0 Ports
12. Optical Device Drive
Bay
13. Emergency Eject Hole
14. Security Lock Slot
15. Battery
16. Component Bay Cover
17. Hard Disk Bay Cover
18. Speakers

Overheating
To prevent your computer from overheating
make sure nothing blocks any vent while the
computer is in use.
Disc Emergency Eject
If you need to manually eject a disc (e.g. due
to an unexpected power interruption) you
may push the end of a straightened paper
clip into the emergency eject hole. Do not
use a sharpened pencil or similar object that
may break and become lodged in the hole.

USB 3.0 Port
The USB 3.0
ports
are col-
ored blue. USB
3.0 will transfer
data much faster
than USB 2.0,
and is back-
wards-compati-
ble with USB 2.0.
8
16
15
6
17
18 18
6
6
11
