System Map: Bottom View 1 - 13

Quick Start Guide

1

System Map: Bottom View

Figure 1 - 6

Bottom View

1.

Battery

2.

Component Bay
Cover

3.

Fan Intake/Vent

4.

Hard Disk Bay
Cover

5.

Speakers

2

1

4

3

CPU

The CPU is not a user serviceable part.

Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake
while the computer is in use.

3

5

5

3

3

Battery Information

Always completely dis-
charge, then fully charge,
a new battery before us-
ing it. Completely dis-
charge and charge the
battery at least once ev-
ery 30 days or after about
20 partial discharges.
See

“Battery Informa-

tion” on page 3 - 11

for

full instructions.
