Upgrading The Computer
Upgrading the System Memory (RAM) 6 - 9
6
5. The RAM module will pop-up, and you can remove it.
6. Pull the latches to release the second module if necessary.
7. Insert a new module holding it at about a 30° angle and fit the connectors firmly
into the memory socket.
8. The module’s pin alignment will allow it to only fit one way. Make sure the module
is seated as far into the socket as it will go. DO NOT FORCE the module; it should
fit without much pressure.
9. Press the module in and down towards the mainboard until the socket levers click
into place to secure the module.
10. Replace the cover and screws (see Figure 6 - 7 ).
11. Restart the computer to allow the BIOS will register the new memory configuration
as it starts up.
15
15
Figure 6 - 10
RAM Module
Removal
