Interface (Ports & Jacks)
A - 4 Interface (Ports & Jacks)
A
Mini-IEEE 1394 Port
This allows high-speed connection to various peripheral devices, e.g. external disk drives and
digital cameras (see note below).
RJ-11 Phone Jack
This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11
telephone connection.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.
RJ-45 LAN Jack
This port supports LAN (Network) functions.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.
S/PDIF-Out Jack
This S/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect your DVD-
capable PC to a Dolby AC-3 compatible receiver for “5.1” or ‘dts’ surround sound.
Security Lock Slot
To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be
purchased at any computer store.
Item
Description
IEEE 1394
The Mini-IEEE 1394 ports only support SELF POWERED IEEE 1394 devices.
