System Map: LCD Panel Open - Model A Design I
Figure 1 - 2
LCD Panel Open -
Model A Design I
1. Built-In PC Camera
(Optional)
2. LCD
3. Power Button
4. Hot Key Buttons
5. LED Status
Indicators (see
Table 1 - 3, on
page 1 - 12
)
6. Keyboard
7. Built-In Microphone
8. Touchpad &
Buttons
Touchpad Buttons
(valid operation area)
8
2
4
1
6
7
3 5
8

Wireless Device
Operation Aboard
Aircraft
The use of any portable elec-
tronic transmission devices
aboard aircraft is usually pro-
hibited. Make sure the mod-
ule(s) are OFF if you are
using the computer aboard
aircraft.
Use the key combinations to
toggle power to the 3.75G/
HSPA/WLAN/Bluetooth
modules, and check the LED
indicator or on-screen icon to
see if the modules are pow-
ered on or not (see
Table 1 -
6, on page 1 - 18 / Table 1 -
2, on page 1 - 12 ).
Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines
indicated on the right.
