Toggle left for
base heating
OPERATION
1) Plug unit into electrical outlet.
2) Place bases/plates into the dispensers, as needed, or until
they are filled to the top. Make sure the load is leveled on the
shelf or it could bind.
3) Place the lids on the top of the unit.
4) If you are heating plates, flip the switch to the right for plate
heating. If you are heating bases, flip the switch to left the for
base heating.
5) Heat up time for bases and plates varies, depending on the
number and style of each. Minimum heat up time for a full unit
is one hour.
6) After heating, remove lid(s) and hang on storage hooks, locat-
ed at each end of the cabinet.
7) Carefully dispense plates/bases.
8) When not in use, turn unit off and keep covers on tubes.
Toggle power switch:
PBH2S
CAUTION : If you
have a heated dis-
penser, exposed sur-
faces of the dispenser can be
hot and may cause burns
CAUTION: PINCH
HAZARD
Hold plates/bases by the
sides when loading the dis-
penser
Holding plates/bases by the
bottom can allow fingers to
become trapped between the
plates and dispenser wall
PBH2S Model:
These cabinets are adjustable to hold plates and/or bases. Each
tube is independently controlled so you can hold either plates or
bases. Refer to page 5 to adjust the spring tension in each tube
for plates or bases prior to loading them.
CAUTION: Plates, bases and exposed surfaces of the dis-
penser will be HOT! Operators should always wear gloves
or use base/plate lifters when dispensing.
Toggle right for
plate heating
Center
position is
OFF
4
