SECTION 1
General Information
1.1 Introduction
The Submarine/Horizontal Gel units offer gel sizes (14 x 20cm) GCSGU-014T-02, (20 x 20cm)
GCSGU-020T-02, (20 x 30cm) GCSGU-030T-02, (20 x 40cm) GCSGU-040T-02, (26 x 14cm)
GCSGU-2614T-02 (26 x 26cm) GCSGU-2626T-02, and GCSGU-2640T-02 (26cm x 40cm). In
the Submarine/Horizontal gel units, the unique tapered baffle system allows immediate gel
casting directly onto the removable UV transparent gel tray without having to seal with agar or
tape. Casting can also be done outside the unit by placing the gel tray into the friction-fit external
gel casting tray. The UV transparent slotted gel tray configuration allows for single or multiple
sample separations. When the gel tray is used in combination with multiple sample combs,
designed for multi-channel pipette loading, screening of large sample numbers can be easily
facilitated. The Submarine/Horizontal Gel units come equipped with an integral cooling chamber
for temperature control and recirculation ports for proper maintenance of buffer pH.
1.2 Specifications
Constructions:
Buffer chamber, safety cover Acrylic
Electrodes Platinum wire .010" diameter
Power cords FR silicone rated 7500VDC,
200mA, 65°C
Tapered baffles Acrylic
Combs Polycarbonate, Anodized Aluminum or
Teflon
Adjustable comb backing Acrylic or anodized aluminum
UVT Gel Tray UV transparent acrylic
Safety Certification EN61010-1-1993 (IEC1010-1)
SGU-014T-02 SGU-020T-02 SGU-030T-02 SGU-040T-02 SGU-2614T-02 SGU-2626T-02 SGU-2640T-02
Shipping
Weight 9 lb. 11 lb. 15 lb. 19 lb. 12 lb. 16 lb. 20lb.
Overall Size
(l)x(w)x(h) cm
38 x 15 x 10 43 x 21 x 10 53 x 21 x 10 63 x 21 x 10 38 x 28 x 10 48 x 28 x 10 64 x 28 x 10
Gel Size - cm 14 x 20 20 x 20 20 x 30 20 x 40 26 x 14 26 x 26 26 x 40
Recommended
buffer volume
with gel tray mls
1500 1850 1950 2050 2200 2600 3400
Distance
between
electrodes -cm
33 38 48 58 30 43 55
Voltage limit 500 VDC 500 VDC 600 VDC 600 VDC 500 VDC 500 VDC 600 VDC
1.3 Safety
Power to the Submarine/Horizontal gel units is to be supplied by an external DC voltage power
supply that must be ground isolated so that the DC voltage output floats with respect to ground.
For any power supply used, the maximum specified operating parameters for the units are:
Maximum Limits
500-600 VDC
20 watts power
90mA current
55°C ambient temperature
Current to the unit, provided from the external power supply, must enter the unit through the lid
assembly, providing a safety interlock to the user. Current to the unit is broken when the lid is
removed. Do not attempt to use the unit without the safety lid, and always turn the power
supply off before removing the lid, or when working with the unit in any way. Follow
safety precautions specified by the power supply manufacturer.
