www.cbsscientific.com

Horizontal Productivity Packages 9/2011

11


3.5 Maximum Well/Comb Volumes

NOTE: To calculate sample well volume expressed in millimeters (mm) of height, divide maximum
volume by tooth depth.


TABLE 1---Combs for 14cm wide unit

SGC14

Combs for

14cm wide

unit

# of wells

Tooth

Depth

mm

Spacing

between

teeth

mm

Overall

length

of comb

mm

Tooth
width/

mm

1.0mm

thickness

volume per

tooth

microliters

(ul)

1.5mm

thickness

volume

per tooth

microliter

s (ul)

2.0mm

thickness

volume per

tooth

microliters

(ul)

3.0mm

thickness

volume per

tooth

microliters

(ul)

1

12.7

3

120.64

120

1524

2286

3048

4572

3E

12.7

3

120.64

38.1

483.87

725.81

967.74

1451.61

5

12.7

3

120.64

21.6

274

411.48

548

822

10

12.7

3

120.64

9.2

117

175.26

232

350

12

12.7

2.4

120.64

7.8

99

148.59

198

297

13

12.7

2.4

120.64

6.6

83.82

125.73

167.64

251.46

16

12.7

2.4

120.64

5.3

67.3

100.9

134.6

201

20

12.7

1.6

120.64

4.5

57

85.7

114

171

26

12.7

1.6

120.64

3.1

39.3

59

78

118

27

12.7

1.6

120.64

2.93

37.21

55.82

74.42

111.63

TABLE 2---Combs for 20cm wide unit

SGC20

Combs for

20cm wide

unit

# of wells

Tooth

Depth

mm

Spacing

between

teeth

mm

Overall

length

of comb

mm

Tooth
width/

mm

1.0mm

thickness

volume per

tooth

microliters

(ul)

1.5mm

thickness

volume

per tooth

microliters

(ul)

2.0mm

thickness

volume per

tooth

microliters

(ul)

3.0mm

thickness

volume per

tooth

microliters

(ul)

1

12.7

3.17

180

180

2286

3429

4572

6858

3E

12.7

3.17

180

49.73

631.57

947.35

1263.14

1894.71

3M

12.7

3.17

180

73.66

935.48

1403.22

1870.96

2806.44

5

12.7

3.17

180

33

419

628

838

1257

8

12.7

2.38

180

20.5

160.3

390

520.6

780

12

12.7

2.38

180

12.8

162.5

243

325

487.6

16

12.7

2.38

180

9

115

172

230

345

20

12.7

2.38

180

6.7

86.1

129

172

258

30

12.7

1.57

180

4.5

57

85.5

114

171

40

12.7

1.57

180

3

37.97

56

75

113


TABLE 3---Combs for 26cm wide unit

SGC26

Combs for

26cm wide

unit

# of wells

Tooth

Depth

mm

Spacing

between

teeth

mm

Overall

length

of comb

mm

Tooth
width/

mm

Marker

width/

mm

.75mm

thickness

volume per

tooth

microliters

(ul)

1.0mm

thickness

volume

per tooth

microliters

(ul)

1.5mm

thickness

volume per

tooth

microliters

(ul)

2.0mm

thickness

volume per

tooth

microliters

(ul)

25

10

2

247

7.1

1 @ 7.1

53.25

71

106.5

142

26

12

2

247

7

N/A

63

84

126

168

27

10

2

247

7

3 @ 5.6

52.5

70

105

140

28

10

2

247

7

4 @ 3.1

52.5

70

105

140

51

10

1

247

3.5

N/A

26.25

35

52.5

70

102

10

1

247

1.45

N/A

10.88

14.5

21.75

29
