INSTALLATION CHECKLIST
0
Check for parts shown on front of QuickStart
Installation Guide
0 Read Warning and Cautions (page 3)
0 Read QuickStart Installation Guide for
mounting instructions
0
Read System Overview, Mounting Considerations,
Detailed Wiring, and Sensing Description (pages 4–9)
0
Read QuickStart Installation Guide for
installation notes
0
Follow Initial System Setup instructions (page 13)
0
Configure Displays (page 53)
0
Configure Alarms (page 61)
1
Specifications subject to change. See www.bluesea.com for current information.
SPECIFICATIONS
2
DC Specifications:
Nominal System Voltage 12 or 24 Volts
Operating Voltage
8.5–33.0 Volts
Minimum Current Draw [email protected] Volts, 18.8mA@24 Volts
Voltage Accuracy +/- 0.5%
Current Range 0–500 Amps
Current Accuracy +/- 1.0%
AC Specifications:
Nominal System Voltage 120 Volts@60 Hz—North America
230 Volts@50 Hz—Typical of Europe
Operating Voltage 0–300 Volts
Voltage Accuracy (RMS) +/- 0.5%
Current Range 0–150 Amps
Current Accuracy (RMS) +/- 2.0%
Frequency 40–90 Hz
Regulatory
EC Declaration of Conformity (page 92)
VSM 422 Surface Mount Gasket creates an IP67 waterproof seal on unit
face
—temporary immersion for 30 minutes
NOTE: Panel mount configurations are not waterproof.
Magnetic Compass Deviation
Compass safe working distance is 10.00" (250mm) from VSM 422 Head Unit.
RESOURCE INFORMATION
Application Briefs:
State of Charge (SOC) http://bluesea.com/viewresource/1324
AC Current Measurement http://bluesea.com/viewresource/86
