Optional Input Configuration
Connection to pin 3 on Header C can be configured to one of three options,
battery 3 monitoring, tank 3 monitoring, or bilge monitoring.
1. Page through main screens by pressing NEXT until the
SYSTEM SUMMARY page is visible.
2. Press SETUP
3. Scroll to and press SELECT on OPTIONAL INPUT
4. Scroll to and press SELECT on desired optional input for system.
5. Press EXIT to return to main system screens.
