(3) Part list
1.Compressor Assy x1
2. Compressor tube x1
3. Intake manifold x 1
4. Intake pipe x 1
5. Compressor gasket x 1
6．Alternator bracket x 1
7．Bracket A x 1
8．Tension bracket B x 1
9．Bracket x 1
10．Trans. Bracket x 1
11．Dip stick bracket
x 1
12．Tension bolt x 1
13．Tension adjuster x 1
18. Ex. Manifold gasket x
1
19. Throttle body gasket
x
1
20. Belt x1
17．Spacer B x 2
φ２２-φ１０ ｈ=４mm
16．Spacer A x 1
φ１８-φ８ ｈ=７mm
15．Spacer x 1
φ２２-φ１２ ｈ=１６．５mm
14．Pulley x 1
