Barranca Diamond Fireball Sphere Machine Manual Effective Date 9/28/06 6
Fireball Sphere Machine Specifications
Motor Baldor VM3545
Horsepower 1 HP
Motor Voltage 220V / 50-60 Hz
Input Voltage 120V / 60 Hz
Amperage 7 Amps
Motor RPM Range 115 to 1725
Shaft RPM Range 50 to 120
Arbor Size 1/2"-13 thread
Adjustable Speed Drive Controller Baldor 1D150201-ER
Max Sphere Size 8" Diameter
Machine Dimensions L x W x H 70" x 24" x 48"
Dry Weight 650 lbs.
Part Number 8303000
Motor
Single phase, continuous duty. Baldor VM3545 motor does not contain automatic thermal protection or reset
button.
Grinding Head Drive Mechanism
Stainless steel rod with belt and pulley system. Moveable grinding head is adjusted by hand crank screw rod.
Cooling/Flushing System
Submersible electric water pump feeds a nozzle directed water flushing system using a plastic collection pan.
Nozzle is on a magnetic mount and is manually adjusted. Submersible pump should only be used with clean
and not with water recycled from collection pan.
Shaft Bearings
Sealed flange mount ball bearings with zerk fittings for grease lubrication. Double sealed, watertight shaft
bearing below grinding area.
Engagement/Disengagement Control
Lever operated clutch system using silicon bronze shoe with block (adjustable set screws).
Indexing of Moveable Grinding Head
Crank handle operated stainless steel screw system to adjust horizontal position of moveable grinding cup.
Vertical angle of cups position adjusted by knob screws (2).
Frame Legs
14 gauge steel construction with locking casters.
ON/OFF Power Control
Variable speed power controller and toggle switch box.
