Barranca Diamond FIREBALL 2 AXLE SPHERE MACHINE User Manual
Page 14

Barranca Diamond Fireball Sphere Machine Manual Effective Date 9/28/06
1
Parts List Fireball Sphere Grinding/Polishing Machine
Part #
Part Description/Specification
Quantity
VM3546
Motor, Baldor, 1HP, 220v, 60Hz 3 Phase 1725 RPM 56C
1
ID15J101-ER
AC Inverter (variable speed control) 120 volts, 50/60Hz
1
GF1818AG
Gear reducer box 10:1 Baldor 918 series
1
135855
Linear bearing assembly, MK-1O1 frame
2
134759
Bar, chrome plated, 3/4" MK-1O1 guide bar
2
5968K43
Bearing, flange mount, 3/4" bore
2
6670K21
Bearing, flange mount 3/4" bore stainless inserts waterproof
1
1517771
Cover, guide bar MK-101
2
152393
Spacer, guide bar nylon MK-1O1
4
154636
Arbor shaft assembly 3/4 shaft MK-2000/5000
2
98805A036
Rod, threaded 3/4-16 stainless
20"
88915K71
Rod, solid 3/4 stainless
48"
6867K67-7/8
Gear, spur 4" OD 48 teeth 14.5 degree angle 7/8" bore no hub
1
6867K67-3/4
Gear, spur 4" OD 48 teeth 14.5 degree angle 3/4" bore
1
6432K21
Collar, 3/4" bore zinc plated
2
6204K21
Pulley, cast iron 3/4" bore x 4" OD
2
6204K32
Pulley, cast iron 3/4" bore x 6" OD
2
100375V38105
Fenner belt, 1/2" wide x 36"
1
JFI-2024-24
Igus bushing synthetic 1-1/4" OD
2
NA
Garlock bushing, synthetic 3/4" ID x 7/8" OD x 3/4" Long
3
523009
Cup to shaft 3/4" adaptor, custom 1/2"-13 thread steel
2
10095K49
Loc-Line manifold for nozzle 1/4" hose
1
10095K11
Loc-Line hose assembly 1/4" hose 13 inch long
1
155987
Pump, Lil’ Giant submersible MK-370 saw
1
6022K38
Handle, crank revolving, aluminum dished 6" OD
1
60205K49
Knob, stainless threaded blind hole 1/2"-20
2
157736
Pan, plastic MK-370 saw
1
9949T96
Wheel, caster 3" x 1-1/4" with swivel brake
4
92620A745
Cap screw, 1/2"-20 x 1-1/4" zinc plated
4
97345A700
Shoulder bolt 1/2"-20 x 1-1/4" zinc plated
4
159865
Box, aluminum switch MK-212 30 Amp
1
159539
Cover, switch box MK-212
1
159489
Plate, switch box MK-212
1
159490
Lever, switch box MK-212 On/Off
1
158799
Bushing, switch box MK-212
1
159492
Seal, lever switch, MK-212
1
159491
Gasket, cover MK-212
1
159909
Cord, 18/3 SJTW x 5-1512 MK-212
1
7082K23
Cord, 14/3 SJEOW 300 VAC
60"
152610
Ground fault circuit interrupter switch 110 volts 15 amps 1
1
91105
Diamond sphere grinding cup 4-3/4" OD x 1/2"-13 thread
2
91106
Diamond sphere grinding cup 5-3/4" OD x 1/2"-13 thread
2
