39
VELOCITY FUSE REPLACEMENT
DANGER !
Do not attempt to remove the velocity fuse until the lift is securely
supported with the maintenance locking devices and all hydraulic pressure
has been removed from the lifting cylinders and hydraulic hoses. Failure
to follow these instructions could result in personal injury or death!
Never attempt to take a velocity fuse apart and repair it. These are precision devices
that are factory assembled under exacting conditions. Velocity fuses should always be
replaced.
1. The arrow on the exterior surface of the velocity fuse shows the direction of the
restriction to the oil flow. The arrow should always point away from the cylinder.
2. Do not use Teflon tape on the threaded connections of a velocity fuse. Tape
fragments can cause malfunctioning of the fuse.
3. Check all fitting connections for hydraulic leaks and tighten as necessary.
HOSE ORIENTATION
To prevent damage to the cylinder hose and possible failure of the lift, it is necessary to
establish a correct hose shape and pattern of movement as follows:
1. Raise the platform to its full height and block securely. See “Lift Blocking
Instructions”.
2. Install one end of the new hose to the cylinder elbow fitting.
3. Lower the lift carefully and check to see that the hose is free and clear of the cylinder
and all structural members. If not, twist the hose in the direction necessary to clear it
of any obstruction and then lock the swivel fitting securely.
GENERAL MAINTENANCE
