11
Model Lifting
Cap.
(lbs)
Std.
Motor
HP
Axle Load
Capacity
Over
Bridge End
(lbs)
Max
Raised
Height
(Inches)
Min.
Lowered
Height
(Inches)
Travel
Speed
Platform
Size
(Inches)
Base Frame
Size
(Inches)
Ship
Wt
(lbs)
PLD-20 2,000 _ 1,500 62 6 1/2 6 60 x 844 8 x 78 1,200
PLD-30 3,000 _ 1,500 62 6 1/2 6 60 x 844 8 x 78 1,350
PLD-50 5,000 5 3,000 61 1/2 6 12 72 x 96 70 x 93 1/2 3,000
NOTE: All models have 2 rams, an approach ramp size of 24” x 48”, and have a
maximum travel of 55 _”.
LOAD CAPACITY
The load capacity rating is stamped on a metal plate attached to one side of the lift.
This figure is a net capacity rating for a lift furnished with the standard platform. The
relief valve of the pumping unit has been set to raise the weight, plus a small amount for
overload. Where gravity roll-sections, special tops, etc, are installed on the lift after
leaving the plant, deduct the weight of these from the load rating to obtain the net
capacity. Lifts should not be overloaded beyond the established capacity as
damage and/or personal injury may result.
UNBALANCED LOADING
The stabilization provided is basically for balanced loads. If special attachments extend
beyond the length and/or width dimensions of the platform, the end and/or side load
capacity must be reduced (contact an Autoquip Sales representative).
PUMP PRESSURE
This lift incorporates a positive displacement pump machined to a high degree of
accuracy and specially adapted to requirements of higher-pressure ranges over that of
a standard pump. Therefore, standard factory models of the same manufacture cannot
replace it.
The pump can operate efficiently at intermittent pressures up to 3200 PSI and
continuous duty to 2500 PSI. The safety relief valve in the pump assembly is factory-
set to stay within the parameters of the pump and lift requirements.
SPECIFICATIONS
