Autoquip TITAN SCISSOR LIFT TABLE User Manual
Page 48
48
Part #
Description
20022158
14DU12 Bushing (Ram)
20022851
18DU12 Bushing (Legs at Platform/Base Clevis)
20022877
18DU16 Bushing (Legs at Platform/Base Clevis)
20023966
24DU24 Bushing
52500154
Pin, Ø1-1/8" x 1-3/4"L, (2) Ring Groove (Base/Platf Clevis)
52500254
Pin, Ø1-1/8" x 1-3/4"L, (1) Ring Groove (Roller)
52600269
Roller Assembly, Ø3” x 3/4” Thick, With Bushing
24004509
Washer, 1/64" Thick for Ø1-1/2" Pin
24012502
Washer, 1/16" Thick for Ø1-1/2" Pin
24002008
Washer, 1/64" Thick for Ø1-1/8" Pin
24001000
Washer, 1/64" Thick for Ø7/8" Pin
24008005
Washer, 1/32" Thick for Ø7/8" Pin
45400082
Retaining Ring for Ø1-1/8" Pin
45400108
Retaining Ring for Ø1-1/2" Pin
52500261
Pin, Ø7/8" x 15-1/4"L, (2) Hole (Trunnion)
52500352
Pin, Ø7/8" x 6-7/8"L, (2) Hole (Trunnion)
27000322
Roll Pin for Trunnion Pins
42300005
Ram, Ø2-1/4" x 14-1/4"Stroke, 1/4" Port
42300013
Ram, Ø2-1/4" x 9-3/8"Stroke, 1/4" Port
42300021
Ram, Ø2-1/4" x 20"Stroke, 1/4" Port
41401820
Foot & Rod Assembly for 14-1/4" Ram
48101830
Foot & Rod Assembly for 9-3/8" Ram
48101840
Foot & Rod Assembly for 20" Ram
48200018
Ram Case Assembly for 14-1/4" Ram
48200026
Ram Case Assembly for 9-3/8" Ram
48200034
Ram Case Assembly for 20" Ram
48350052
Foot for Ram
22040935
FHSCS, 3/4-10 x 1-1/2", Nylok, For Ram Foot
45500246
Seal Kit for Ram
45901014
Bleeder Screw Seal for Ram
22300313
Bleeder Screw For Ram
44810026
Ram Retainer Bar, Formed
34100388
Limit Switch, (1)NO & (1)NC
34100470
Lever Arm for Limit Switch
41501776
Hydraulic Flow Control Valve, 1-1/2 GPM, 3/8 FNPT
41502840
Hydraulic Flow Control Valve, 3 GPM, 3/8 FNPT
41800640
Hydraulic Velocity Fuse, 1-1/2 GPM, 1/4 FNPT
41800541
Hydraulic Velocity Fuse, 2 GPM, 1/4 FNPT
41800566
Hydraulic Velocity Fuse, 2-1/2 GPM, 1/4 FNPT
41800681
Hydraulic Velocity Fuse, 3 GPM, 3/8 FNPT
41800517
Hydraulic Velocity Fuse, 3-1/2 GPM, 1/4 FNPT
41800591
Hydraulic Velocity Fuse, 6-1/2 GPM, 3/8 FNPT
41000191
Up-Stop Valve
46000022
Hose, 1/4” x 9” with fittings
46000048
Hose, 1/4” x 14” with fittings
46000055
Hose, 1/4” x 18” with fittings
46000071
Hose, 1/4” x 24” with fittings
46000089
Hose, 1/4” x 30” with fittings
46000097
Hose, 1/4” x 36” with fittings
46000105
Hose, 1/4” x 48” with fittings
