15
3. Verify installation area is clean before starting. Check mounting surface of pit floor with a level or
straight edge. If floor is not level, add shims or grout under entire perimeter of base to achieve a
level and flat base installation. A level base is essential for proper wheel tracking and smooth lift
operation.
Prevent serious injury or death.
Depending on model, weight of lift ranges from 1000 – 5000 lbs.
Use a properly rated lifting device to move and install lift.
4. Lower lift into pit and check for proper height. Lift must be solid and flush with pit curb angle framing
(D). If needed, shim to desired height. DO NOT “spot” shim. Shim along full length of frame. This will
prevent frame from sagging under load.
Prevent serious injury or death.
Electrical service installation must be performed by a licensed
electrician and conform to all local and national electrical codes.
NOTE: For larger horsepower motors, consult factory.
^ WARNING
^ WARNING
HP and Voltage Full Load Amperages
1/2 HP: 115 V /60 CY/1 PH (36S15)
115 Volts = 15.0 Amps
3/4 HP: 115 V /60 CY/1 PH
115 Volts = 16.6 Amps
3/4 HP: 230 V /60 CY/1 PH
230 Volts = 8.3 Amps
3 HP: 115 / 208 / 230V /60 CY/1PH
Heavy Duty Motor (Not Intermittent)
115 V = 33.6 Amps
208/230V=16.8
Amps
5 HP: 230 V /60 CY/1 PH
Heavy Duty Motor (Not Intermittent)
230 Volts = 23.0 Amps
1-1/2 HP: 208 / 230 V /60 CY/3 PH
208 / 230 V= 5.3 Amps
1-1/2 HP: 460 V /60 CY/ 3 PH
460Volts = 2.85 Amps
5 HP: 208 / 230 V /60 CY/3 PH
Intermittent Duty Motor
208 V=15.8 Amps 230 V=14.8 Amps
5 HP: 460 V /60 CY/3 PH
Intermittent Duty Motor
460 Volts = 7.4 Amps
5 HP: 208 / 230 V /60 CY/3 PH
Heavy Duty Motor
208 V=16 Amps 230 V=15.2 Amps
5 HP: 460 V /60 CY/3 PH
Heavy Duty Motor
460 V=7.6 Amps
