GL2200 U SER G UIDE 16
G
ROUP
O
UTPUTS
G
ROUPS
Group outputs are controlled by 100mm travel faders which offer a
further 10dB boost above the normal ‘0’ dB operating level.
MUTE switches the group signal off when pressed regardless of fader
position. Muted channels are indicated by red LEDs.
AFL (After Fade Listen) routes the post fader signal to the console
meters and headphone monitoring to allow checks for sound quality and
mix level. The AFL signal is sourced before the MUTE switch allowing
the signal to be checked even when the group is muted.
Each group has a 4 segment LED peak reading meter providing signal
presence indication and peak warning which illuminates approximately
5dB before clipping. Meter activity is interrupted when a group is muted.
S
UB
G
ROUPING
Sometimes it is necessary to control more than one channel
simultaneously, in the case of a drum kit or a group of backing vocalists
for example.
Route the relevant channels to groups instead of L-R, using the channel
routing switches and the pan controls.
PAN control positions the signal in the stereo image with the L-R switch
routing the group mix to the Left & Right masters. Ensure the group L-R
switch is selected to route the group signal to the L-R mix.
In this way, one group fader can control the level of several channels.
It is possible to set up mono or stereo subgroups using the channel and
group PAN controls.
PEAK
0
SIG
+6
PEAK
0
SIG
+6
AUX1 AUX2
1 2
PAN
L-R
2 1
C C
MUTE MUTE
AFL AFL
GRP/AUX 1-2
REVERSE
PAN
L-R
L R L R
OO
20
30
10
5
0
5
10
OO
20
30
10
5
0
5
10
AFL
GROUP MIX
SL
AUX MIX
SL
GROUP4
AUX4
PAN L-R
(R CCT ONLY)
R POST
TO MONITOR
(GROUP CCTS ONLY)
SUBGROUPING
GROUP/RIGHT AFL
-2dBu
INSERT
MUTE
--
FADER
AUX
-
PEAK
BAL
+
SIG
+6dB
0dB
GROUP2
+4dBu
2 = +
AUX AUX
BAL OUT OPTION
+
BAL
OUT GRP
AUX2
RIGHT
AUX
GRP GRP
AUX6
GROUP MIX
SL
AUX MIX
SL
GROUP3
AUX3
+6dB
(GROUP CCTS ONLY)
AUX1-2, AUX3-4, AUX5-6
GROUP1-2, GROUP3-4, L-R
SUBGROUPING
GROUP/AUX REVERSE
SAME FOR
INSERT
-2dBu MUTE
-
PAN
FADER
(L CCT ONLY)
TO MONITOR
L POST
REV
1-2
+
L-R
SIG
0dB
BAL
2 = +
+4dBu
GROUP1
AUX AUX
AFL
GROUP/LEFT
AUX
AFL
-
BAL OUT OPTION
PEAK
BAL
+
OUT GRP
AUX1
REV REV
3-4 L-R
5-6
LEFT
AUX
GRP GRP
AUX5
G
R
P
1
-4
A
U
X
1-
6
P /A
FL
R
IG
H
T
LE
FT
Group / Aux diagram
