Advance Page
The advance setting is shown as follows. The description of each session is said as following:
1. Wireless mode: Select wireless mode. 802.11B only, 802.11 B/G mixed 802.11A only, 802.11
a/b/g mixed and 802.11G only modes are supported.
2. 11B/G Protection: ERP protection mode of 802.11G definition. User can chosse from Auto, On,
and Off
i. Auto: STA will dynamically change as AP announcement.
ii. On: Always send frame with protection.
iii. Off: Always send frame without protection.
3. TX Rate: Manually force the Transmit using selected rate. Default is auto.
4. CCX2.0: support Cisco Compatible Extensions function:
i. LEAP turn on CCKM
ii. Enable Radio Measurement: can channel measurement every 0~2000 milliseconds.
5. Tx Burst: AirLive’s proprietary frame burst mode.
6. Wireless radio signal control
z
: means to open the wireless radio signal and show simultaneously:
z
: means to close the wireless radio signal and show simultaneously:
7. Apply Means the modification of session 1~4 are formally used.
- 23 - AirLive MIMO-G Wireless LAN Adapter User’s Manual
